EQUIPMENT
| 460 LX Fixed Sideframe Tier 3 |
| Weight |
102,956 lbs. |
| Bucket Range |
1.58 - 4.05 cu. yd. |
| Arm Lengths |
8' 4"
11' 1"
13' 1"
15' 11" |
| Digging Depth |
22' 6"
25' 4"
27' 4"
30' 2" |
| Maximum Digging Radius |
36' 10"
39' 4"
41' 2"
43' 11 " |
| Arm Digging Force |
57,100 lbs.
46,310 lbs.
40,690 lbs.
35,740 lbs. |
| Bucket Digging Force |
60,700 lbs. |
| Maximum Swing Speed |
9.0 rpm |
| Travel Speed |
1.9/3.3 mph |
| Gradeability |
70% |
| Engine/Type |
Isuzu AH-6UZ1XYSS
4-Cycle Diesel |
| Net hp @ rpm with fan pump |
329 hp @ 1,950 rpm |
| Net hp @ rpm without fan pump |
362 hp @ 1,950 rpm |
Click here to download full specifications as an Acrobat Reader/PDF
|
|
